Quick Summary
The AMG8833 Infrared Thermal Imaging Camera Array Module is a compact thermal sensing module for industrial measurement and inspection tasks. It combines 8×8 resolution with 64 pixels, a typical viewing angle of 60°, and detection capability up to 7 metres. It is USB powered at 5V, which makes it straightforward to use in portable setups and project integration.
Who It Is Best For
This module suits buyers who need a small thermal imaging sensor for electronic inspection, thermal data capture, or integration into a larger system. It will appeal to users who want a compact device with I²C interface support and clear output for measurement focused applications. If you are selecting it for a specific project, check the operating needs and confirm that the module fits your intended setup.
What To Know Before You Buy
The module is described with a compact 38 x 36 x 17 mm design and a weight of 17 g, so it is easy to work into smaller builds. It also supports normal, sleep, and standby modes, with current consumption as low as 0.2 mA. The listed accuracy is within ±2.5°C and the resolution is 0.25°C.
Pros: Compact, USB powered, and suited to thermal measurement and integration work.
Cons: Check the selected application and setup carefully, especially if you need a specific operating range or output behaviour.
Common Buyer Questions
What is this module used for?
It is designed for infrared thermal imaging and industrial measurement tasks, including electronic inspection and other thermal applications.
Does it connect through I²C?
Yes, it supports an I²C interface for flexible integration into different thermal imaging systems.
How detailed is the thermal sensing?
It uses 8×8 resolution with 64 pixels, which is suitable for compact thermal data capture.
Is it suitable for portable use?
Yes, it is USB powered at 5V and described as compact and lightweight.
What should I check before ordering?
Check that the module suits your intended measurement setup, operating range, and integration needs.
Key Details
| Product type | Infrared thermal imaging camera array module |
| Model | AMG8833 |
| Resolution | 8×8 with 64 pixels |
| Detection distance | Up to 7 metres |
| Interface | I²C |
| Power | USB 5V |
| Accuracy | ±2.5°C |
| Resolution detail | 0.25°C |
| Typical viewing angle | 60° |
| Typical frame rate | 10 frames per second |
| Dimensions | 38 x 36 x 17 mm |
| Weight | 17 g |
| Operating modes | Normal, sleep, and standby |
Final Buying View
The AMG8833 Infrared Thermal Imaging Camera Array Module is a compact thermal sensing option for measurement focused projects, with 8×8 resolution, I²C interface support, and USB 5V power. If you need a small module for thermal inspection or system integration, it offers a practical feature set in a lightweight form. Check your setup requirements before ordering, and it should be a straightforward fit for the right application.
