Quick Summary
This B75 LGA 1155 motherboard is for Intel Core i3, i5 and i7, Xeon E3 V2, Celeron G series and Pentium G series processors. It supports dual channel DDR3 memory up to 16GB and includes M.2 support for NVMe and NGFF connections.
It also provides PCIe x16, ATA3.0, VGA and HDMI, so it brings together several connection options in one board. Check processor support, memory type and the display output you need before ordering.
Who It Is Best For
This board suits buyers building or replacing a system around the stated LGA 1155 platform and the supported processor families. It will also suit anyone looking for a motherboard with DDR3 memory support, M.2 storage support and VGA or HDMI output in the same specification set.
Key Details
| Detail | Verified information and buyer relevance |
|---|---|
| Chipset | B75 chipset for the stated motherboard platform. |
| Socket | LGA 1155, so the CPU must match this socket. |
| Supported processors | Core i3, i5 and i7, Xeon E3 V2, Celeron G series and Pentium G series are stated as supported. |
| Memory | Dual channel DDR3 with two 240 pin slots and up to 16GB total capacity. |
| Memory frequencies | 1066, 1333 and 1600 MHz are listed. |
| M.2 interface | M.2 interface with jumper support for NVME and NGFF connections. |
| Storage mode | Switching between PCIe and ATA3.0 (6GB/s) channels is stated. |
| Expansion | PCIe x16 is included for a compatible expansion card or graphics card. |
| Video outputs | VGA and HDMI are included for display connection when the CPU supports integrated graphics. |
| Power connector | 24+4 pin power connector is stated. |
| Construction | 8 layer PCB and 6 phase power supply are stated in the description. |
What To Know Before You Buy
Confirm that your processor is one of the stated supported families and that it matches the LGA 1155 socket. Check that your memory is DDR3 and that you are comfortable with the 16GB maximum capacity.
If you want to use VGA or HDMI, make sure your CPU supports integrated graphics. Review the M.2 jumper setup and the NVME or NGFF option you plan to use before fitting the board.
Common Buyer Questions
Which processors are supported?
The board is stated to support Core i3, i5 and i7, Xeon E3 V2, Celeron G series and Pentium G series processors for the LGA 1155 platform.
How much memory does it take?
It supports two DDR3 slots with up to 16GB total capacity.
Does it support M.2 storage?
Yes, it includes an M.2 interface with jumper support for NVME and NGFF connections.
Can I use the display ports without a graphics card?
VGA and HDMI are stated, but the CPU must support integrated graphics for those outputs to work.
Final Buying View
This motherboard combines the stated LGA 1155 platform, DDR3 support and M.2 connectivity in one board. It is worth comparing your CPU, memory and display needs against the listed specification before you choose it.
